Showing 1–16 of 73 results
136-1000-04
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Hose Size In: '1/4
Insert Assembly No: 137-1000-04
Mil Spec: M83798/1
NSN No.: '4730-00-618-7278
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
Notes: Dimension B: Cutoff Factor Dimensional Information Is For Reference Only. Variations From These Dimensions On Actual Parts May Occur As The Result Of Engineering Revisions. Part Col
136-1045-04
Dimension G In: '0.352
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.375
Hose Size In: '1/4
Insert Assembly No: 137-1045-04
Mil Spec: M83798/2
NSN No.: '4730-01-101-2064 4730-00-709-3887
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
136-1090-04
Dimension G In: '0.718
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.375
Hose Size In: '1/4
Insert Assembly No: 137-1090-04
Mil Spec: M83798/3
NSN No.: '4730-00-618-8862
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
136-2000-04
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Hose Size In: '1/4
Insert Assembly No: 137-2000-04
Mil Spec: M83798/4
NSN No.: '4730-00936-2362
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
136-2045-04
Dimension G In: '0.450
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.375
Hose Size In: '1/4
Insert Assembly No: 137-2045-04
Mil Spec: M83798/5
NSN No.: '4730-01-240-6110
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
136-2090-04
Dimension G In: '0.860
Dimension H In: '0.159
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.375
Hose Size In: '1/4
Insert Assembly No: 137-2090-04
Mil Spec: M83798/6
NSN No.: '4730-00-936-2367
Socket Assembly No: '136-900-04D
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
147-29034
Hose Size In: '1/4
Ms Part No: Ms27404-4D
NSN No.: '4730-00-497-4281
Thread Size - T: 7/16"-20
148-05200-04
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-54757
Mil Spec: MS27053
NSN No.: '4730-00-055-5689 4730-01-566-3714
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-05212-04
Dimension G In: '0.322
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-31969
Mil Spec: MS27059
NSN No.: '4730-00-889-2465
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-05214-04
Dimension G In: '0.580
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-31981
Mil Spec: MS27060
NSN No.: '4730-00-013-6970
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-05216-04
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-30341
Mil Spec: MS27381
NSN No.: '4730-00-054-7650
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-05217-04
Dimension G In: '0.424
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-07078
Mil Spec: MS27384
NSN No.: '4730-00-057-0665
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-05218-04
Dimension G In: '0.725
Dimension H In: '0.163
Dimension K (in): '0.562
Dimension L In: '0.562
Hose Size In: '1/4
Insert Assembly No: 148-07082
Mil Spec: MS27385
NSN No.: '4730-00-057-0664
Thread Size - T: 7/16"-20
Type 1: Complete Fitting
148-1045-04
Dimension G In: '0.352
Dimension H In: '0.126
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.38
Hose Size In: '1/4
Insert Assembly No: 148-1145-04
Mil Spec: MS27226
NSN No.: '4730-00-541-0487
Thread Size - T: 7/16"-20
Type 1: Complete Assembly
148-1090-04
Dimension G In: '0.718
Dimension H In: '0.126
Dimension K (in): '0.562
Dimension M (in): '0.650
Dimension R In: '0.38
Hose Size In: '1/4
Insert Assembly No: 148-1190-04
Mil Spec: MS27224
NSN No.: '4730-00-541-0486
Thread Size - T: 7/16"-20
Type 1: Complete Assembly
148-2000-04
Dimension H In: '0.126
Dimension K (in): '0.562
Dimension M (in): '0.650
Insert Assembly No: 148-2100-04
NSN No.: 4730-00-068-8608
Socket Assembly No: '148-32104
Thread Size - T: 7/16"-20
Type 1: Complete Assembly
