Showing 1–16 of 83 results

•

  136-1000-10D – Lightweight Medium Pressure Flared Hose Fittings – Straight, Flared

  136-1000-10D

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Hose Size In: '5/8

  Insert Assembly No: 137-1000-10D

  Mil Spec: M83798/1

  NSN No.: '4730-01-444-5459

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  136-1045-10D – Lightweight Medium Pressure Flared Hose Fittings – 45º Elbow, Flared, Bent Tube

  136-1045-10D

  Dimension G In: '0.536

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.625

  Hose Size In: '5/8

  Insert Assembly No: 137-1045-10D

  Mil Spec: M83798/2

  NSN No.: '4730-00-813-6923

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  136-1090-10D – Lightweight Medium Pressure Flared Hose Fittings – 90º Elbow, Flared, Bent Tube

  136-1090-10D

  Dimension G In: '1.126

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.625

  Hose Size In: '5/8

  Insert Assembly No: 137-1090-10D

  Mil Spec: M83798/3

  NSN No.: '4730-00-919-6785

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  136-2000-10D – Lightweight Medium Pressure Flareless Hose Fittings – Straight, Flareless

  136-2000-10D

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Hose Size In: '5/8

  Insert Assembly No: 137-2000-10D

  Mil Spec: M83798/4

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Notes: Dimension B: Cutoff Factor Dimensional Information Is For Reference Only. Variations From These Dimensions On Actual Parts May Occur As The Result Of Engineering Revisions. Part Col

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  136-2045-10D – Lightweight Medium Pressure Flareless Hose Fittings – 45º Elbow, Flareless, Bent Tube

  136-2045-10D

  Dimension G In: '0.725

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.625

  Hose Size In: '5/8

  Insert Assembly No: 137-2045-10D

  Mil Spec: M83798/5

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Notes: Dimension B: Cutoff Factor Dimensional Information Is For Reference Only. Variations From These Dimensions On Actual Parts May Occur As The Result Of Engineering Revisions. Part Col

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  136-2090-10D – Lightweight Medium Pressure Flareless Hose Fittings – 90º Elbow, Flareless, Bent Tube

  136-2090-10D

  Dimension G In: '1.392

  Dimension H In: '0.486

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.625

  Hose Size In: '5/8

  Insert Assembly No: 137-2090-10D

  Mil Spec: M83798/6

  NSN No.: '4730-01-052-6478

  Socket Assembly No: '136-900-10D

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  147-29040 – Low Pressure Hose Fittings – Straight, Flared

  147-29040

  Hose Size In: '5/8

  Ms Part No: Ms27404-10D

  NSN No.: '4730-00-497-4284

  Thread Size - T: 7/8"-14

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05200-10 – Medium Pressure TFE Flared Hose Fittings – Straight, Flared

  148-05200-10

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Equal To Aeroquip No: F66000-10

  Hose Size In: '5/8

  Insert Assembly No: 148-54761

  Mil Spec: MS27053

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05204-10 – Medium Pressure TFE Flared Hose Fittings – 45º Elbow, Flared, Bent Tube

  148-05204-10

  Dimension G In: '0.536

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Dimension R In: '0.62

  Hose Size In: '5/8

  Insert Assembly No: 148-32775

  Mil Spec: Ms27055

  NSN No.: '4730-00-884-1232

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05208-10 – Medium Pressure TFE Flared Hose Fittings – 90º Elbow, Flared, Bent Tube

  148-05208-10

  Dimension G In: '1.126

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Dimension R In: '0.62

  Hose Size In: '5/8

  Insert Assembly No: 148-32655

  Mil Spec: Ms27057

  NSN No.: '4730-00-132-3162

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05216-10 – Medium Pressure TFE Flareless Hose Fittings – Straight, Flareless

  148-05216-10

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Hose Size In: '5/8

  Insert Assembly No: 148-30345

  Mil Spec: MS27381

  NSN No.: '4730-00-489-8251

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05219-10 – Medium Pressure TFE Flareless Hose Fittings – 45º Elbow, Flareless, Bent Tube

  148-05219-10

  Dimension G In: '0.725

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Dimension R In: '0.63

  Hose Size In: '5/8

  Insert Assembly No: 148-30415

  Mil Spec: Ms27382

  NSN No.: '4730-00-008-4806

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Notes: Dimension B: Cutoff Factor Dimensional Information Is For Reference Only. Variations From These Dimensions On Actual Parts May Occur As The Result Of Engineering Revisions.

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-05220-10 – Medium Pressure TFE Flareless Hose Fittings – 90º Elbow, Flareless, Bent Tube

  148-05220-10

  Dimension G In: '1.392

  Dimension H In: '0.443

  Dimension K (in): '1.000

  Dimension L In: '1.000

  Dimension R In: '0.62

  Hose Size In: '5/8

  Insert Assembly No: 148-30475

  Mil Spec: Ms27383

  NSN No.: '4730-00-407-0512

  Thread Size - T: 7/8"-14

  Type 1: Complete Fitting

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-1045-10D – Medium Pressure Rubber Flared Hose Fittings – 45º Elbow, Flared

  148-1045-10D

  Dimension G In: '0.536

  Dimension H In: '0.455

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.62

  Hose Size In: '5/8

  Insert Assembly No: 148-1145-10D

  Mil Spec: MS27226

  NSN No.: '4730-00-540-1083

  Thread Size - T: 7/8"-14

  Type 1: Complete Assembly

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-1090-10D – Medium Pressure Rubber Flared Hose Fittings – 90º Elbow, Flared

  148-1090-10D

  Dimension G In: '1.126

  Dimension H In: '0.455

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Dimension R In: '0.62

  Hose Size In: '5/8

  Insert Assembly No: 148-1190-10D

  Mil Spec: MS27224

  NSN No.: '4730-00-541-3154

  Thread Size - T: 7/8"-14

  Type 1: Complete Assembly

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List

•

  148-2000-10D – Medium Pressure Rubber Flareless Hose Fittings – Straight, Flareless

  148-2000-10D

  Dimension H In: '0.455

  Dimension K (in): '1.000

  Dimension M (in): '1.16

  Insert Assembly No: 148-2100-10D

  NSN No.: 4730-01-078-8598

  Socket Assembly No: '148-32110

  Thread Size - T: 7/8"-14

  Type 1: Complete Assembly

  Compare QUOTE
  Request Information

  Product successfully added to the Quote List
